RJ9W

Lift 4,082-kg. for Full Wheel Service Capability

With a ​6,350-kg. capacity ​lift, you might think the R​J7W jacking beam is sufficient for your vehicle. However, vehicles that max out a lift's capacity might have offset centers of gravity. In such cases, the R​J7W is not suitable to lift those vehicles. That’s why we offer the R​J9W. A heavier-duty jacking beam can save you from having to swap your perfectly fine four-post lift for a heavier-duty model.

Rubber contact pads

Rubber contact pads are essential lifting components. They increase rise and firmly engage your vehicle’s undercarriage lift points. The durable yet non-marring surface ensures vehicles are not scraped or damaged during ​jacking beam or car lift operation.

Stackable adapters

The ability to stack and unstack BendPak contact pads increases the versatility of your ​jacking beam. These adapters are also useful for lifting vehicles that may have drastically different front-and-rear suspensions. With two jacking beams employed at once, the front may need an extra adapter to ensure an even lift.

High-pressure hydraulic power unit

BendPak’s ​jacking beams include a pneumatic-hydraulic power unit that comes attached to the jack. The car lift runs off its own power unit, so there’s no “sharing” of hydraulic power between the two. An airline must be attached to the jacking beam with 125 psi and 10 – 20 CFM. Easy foot pedal control is included for your safety and convenience.

Three lock levels

With three lock positions, your jacking beam can be raised to the level most comfortable for you. Find the perfect height for the perfect job as you also adjust the height of your car ​lift.

Features

• 4,082-kg. lifting capacity
• Easy-Roll Wheels
• Rubber contact pads
• Stackable adapters
• High-pressure hydraulic power unit
• Optional air-line kit
